The loader bucket lifting mechanism

The lifting mechanism is composed of an electric motor, a speed reducer, a lifting chain and a winding drum.

Loader rotating mechanism

The rotary mechanism is the role of the working mechanism of bucket in the horizontal plane and the left and right rotation, so that the bucket can be installed on both sides of the roadway rock, enlarge loading width; main components of rotary mechanism with revolving seat consists of two turntables and a guiding device, the rotation angle can be directly controlled by the operator (general can rotate to the left and right 30. ), so as to increase the width of loader bucket. At the same time, when the rotary rotary angle, the bucket loader lifting bucket back and discharging time, rely on the guide device can ensure the automatic revolving seat is guided to the middle position, and not the rock unloading car outside.

Loader walking mechanism

The walking mechanism of coal mine use after discharge bucket loader for rail wheel, comprising a motor, deceleration of two and the front and rear wheels.
